Part name | CX9030B CX9021 TRAVEL DEVICE |
Equipment | Apply to CASE Excavator |
CASE CX9030B CX9021 | |
| Stock code | 9202931 |
| Category | Construction Machinery Parts, Excavator Spare Parts |
| Installation | UNDERCARRIAGE |
| Application | Replacement |
| Item condition | NEW |
| Logo | BN |
| MOQ | 1pc |
| Pos. | Part No | Qty | Parts name |
| 160146A1 | [1] | GEAR WHEEL | |
| 1 | 160094A1 | [1] | GEAR WHEEL |
| 2 | 160004A1 | [3] | SUN GEAR |
| 3 | 160278A1 | [3] | BEARING, NEEDLE,30mm ID x 40mm OD x 19.8mm W |
| 4 | 160029A1 | [3] | LARGE PIN |
| 5 | 160291A1 | [6] | THRUST WASHER |
| 6 | 160109A1 | [2] | PIN, ROLL |
| 160144A1 | [1] | HOLDER | |
| 7 | 160095A1 | [1] | GEAR WHEEL |
| 8 | 160005A1 | [4] | SUN GEAR |
| 9 | 160273A1 | [4] | NEEDLE BEARING,35mm ID x 51mm OD x 24.8mm W |
| 10 | 160030A1 | [4] | SHAFT |
| 11 | 160043A1 | [3] | THRUST WASHER |
| 12 | 160098A1 | [4] | PIN, ROLL |
| 160145A1 | [1] | GEAR WHEEL | |
| 13 | 160207A1 | [1] | HOLDER |
| 14 | 160010A1 | [4] | SUN GEAR |
| 15 | 160326A1 | [68] | ROLLER |
| 16 | 160031A1 | [4] | SHAFT |
| 17 | 160037A1 | [4] | BUSHING |
| 18 | 160093A1 | [8] | COLLAR |
| 19 | 160044A1 | [8] | THRUST WASHER |
| 20 | 160099A1 | [4] | PIN, ROLL |
| 21 | 160007A1 | [1] | PINION |
| 22 | 160038A1 | [1] | PLATE, THRUST |
| 23 | 160008A1 | [1] | SUN GEAR |
| 24 | 160009A1 | [1] | SUN GEAR |
| 25 | 155643A1 | [1] | RING, SNAP |
| 26 | NSS | [1] | NOT SOLD SEPARAT |
| 27 | 156144A1 | [2] | BEARING, BALL,240mm ID x 310mm OD x 32mm W |
| 28 | NSS | [1] | NOT SOLD SEPARAT |
| 29 | 160223A1 | [1] | SHIM KIT |
| 30 | 160104A1 | [4] | PIN |
| 31 | 863-16090 | [4] | HEX SOC SCREW,M16 x 90mm, Cl 12.9 |
| 32 | 863-18055 | [16] | HEX SOC SCREW,M18 x 55mm, Cl 12.9 |
| 33 | 156338A1 | [4] | PLATE |
| 34 | 160006A1 | [1] | PINION |
| 160575A1 | [1] | SEAL KIT | |
| 35 | 155299A1 | [1] | SEAL |
| 36 | 155183A1 | [1] | O-RING |
| 37 | 156200A1 | [16] | BOLT,M14 x 95mm |
| 38 | 155647A1 | [3] | COTTER PIN |
| 39 | 160220A1 | [1] | SET OF PARTS |
| 40 | 160325A1 | [1] | COVER |
| 41 | 863-10020 | [16] | HEX SOC SCREW,M10 x 20mm, Cl 12.9 |
| 42 | 151033A1 | [3] | PLUG |
| 43 | 151026A1 | [1] | PLUG |
| 44 | 151022A1 | [1] | PLUG |
| 45 | 892-10016 | [4] | LOCK WASHER,M16 |
| 46 | 155578A1 | [1] | PIN |
| 47 | 160002A1 | [1] | COUPLING |
| 48 | 738-1650 | [1] | LOCK PIN,M6 x 50, Slotted |
◆ Completely, assembly, and ready to installed in your CASE CX9030B CX9021 excavators.
◆ Without motor.
◆ All components are produced by us.
◆ All new, undamaged.
◆ Painted or unpainted, depend on requirement
◆ 1000 working hours warranty, call or email with any questions.
◆ Plywood case packing, free of fumigation
◆ Deliver to worldwide by sea, air, or carrier.
